Project 3D Visualisations, 3D Animations
Engineering design of ground stabilization systems.
Piling and ground reinforcement process – 3D cross-section
3D Animations for Construction and Geotechnics: Ground Stabilization Process
For our client, Aarsleff, we have created a series of specialized 3D animations for construction and geotechnics. These materials showcase modern ground stabilization methods using elements such as:
- Prefabricated and bored piles,
- Micropiles and ground anchors,
- Soil nails and ground improvement systems.
Each animation serves as a comprehensive guide to the technology, featuring not only the machinery but also geological cross-sections that reveal the full depth of the geotechnical works.
Diaphragm Walls – Advanced Engineering in 3D Visualization
One of our key projects is a 3D animation for civil engineering and geotechnics depicting the construction process of diaphragm walls. These are reinforced concrete structures formed directly within a trench excavated in the ground, essential for:
- Metro and urban tunnel construction,
- Deep underground levels of office buildings,
- Complex transport arteries.
Temporary Shoring: Berlin Wall in 3D
Another visualization variant for Aarsleff features Berlin shoring systems, which are crucial for securing deep technological excavations. This 3D technical animation showcases the detailed structure of the system:
- Steel soldier piles (H-beams): driven or vibrated into the ground.
- Timber lagging: installed sequentially as the excavation progresses.
The visualization emphasizes the efficiency conditions of this method, such as the appropriate groundwater level and the safety of neighboring structures. This type of 3D animation for civil engineering and geotechnics is an invaluable tool for technical presentations.
Solid Foundations: Displacement and Bored Piles
Concrete Displacement Piles
Primarily used for ground reinforcement under road and railway embankments. These 3D animations for civil engineering and geotechnics showcase the operation of the displacement head, which densifies the soil horizontally, improving its bearing capacity without removing spoil.
Large-Diameter Bored Piles
A classic method for transferring heavy loads to deep bearing strata. The visualization allows for tracking the casing installation and soil extraction at depths exceeding 30 meters, with diameters up to 1500 mm.
Global Reach and Technical Education
FAQ – Frequently Asked Questions about Technical Animations
1. How long does it take to produce a professional 3D construction animation?
The time required to create 3D animations for civil engineering and geotechnics is directly dependent on the complexity of the scenario and the level of detail of the machinery and processes. The standard production process usually takes from 2 to several weeks. For a precise schedule, it is best to contact an experienced design team that can optimize the workflow to meet your deadline.
2. Can CAD or CAD/CAM files (e.g., STEP format) be used for 3D animations?
Yes, at Modii3D we work directly with provided engineering documentation. Utilizing your CAD files and CAD/CAM formats (such as .step) allows us to maintain 100% technical accuracy. This is crucial for geotechnical animations, where every structural detail—such as reinforcement, precise component placement, or drilling parameters—is essential.
3. Why are 3D animations better for construction than traditional site videos?
3D animation allows you to “see underground” and showcase what remains hidden from a traditional camera. We can visualize pressurized concrete pouring for piles, the operation of ground anchors, or soil behavior, providing immense educational and sales value for companies like Aarsleff.
4. What are the technical requirements to start a 3D visualization project?
To begin, we only need a general description of the technology or a basic scenario. If you have technical drawings, machinery photos, or process specifications, it will significantly speed up the work. Our team handles the rest: from 3D modeling and texturing to final rendering and editing.
5. Do 3D animations support sales processes and tender participation?
Absolutely. Professional 3D video acts as digital proof of competence. It allows investors to understand complex technology in a matter of minutes, which is often a deciding factor when selecting a contractor in the construction and engineering sectors.
If you want to learn more about the process of creating 3D materials, check out these articles:
· What Are .STEP Files and How Do We Use Design Data in 3D Animations?
· Technical and Instructional 3D Animations
· 3D Animations in Advertising
Contact us to learn more!
